PI Real-time Data Sync Guide

This page describes how to use PI real-time tasks to continuously sync real-time data from the PI system to TDengine, covering task configuration, advanced features, best practices, and troubleshooting.

1. Overview

PI real-time tasks continuously subscribe to data changes in the PI system and write newly generated data to TDengine in real time. Typical use cases include:

• Real-time monitoring: Sync PI real-time data to TDengine to build real-time dashboards leveraging TDengine's high-performance query capabilities
• Dual-write transition: Run both systems in parallel during migration from PI to TDengine
• Data aggregation: Aggregate real-time data from multiple PI systems into a unified TDengine cluster

2. Creating a PI Real-time Task

2.1 Basic Steps

1. On the Data In page in Explorer, click +Add Data Source
2. In the Type dropdown, select PI
3. Configure connection information (see main documentation)
4. Configure data model (single/multi-column, see Model Configuration Reference)
5. Configure restart compensation time (see next section)
6. Configure advanced options (see section 4)
7. Submit the task

2.2 Restart Compensation Time

Restart compensation time is a key parameter for PI real-time tasks. When a task is unexpectedly interrupted and restarted, taosX will automatically backfill data from the interruption time to the current time.

Parameter	Description
Restart Compensation Time	Sets the maximum time window for automatic backfill after restart

Configuration recommendations:

• Set based on the maximum data loss duration you can tolerate
• For example, if set to 1 hour and the task was interrupted for 30 minutes before restart, taosX will backfill the 30 minutes of data
• If the interruption duration exceeds the compensation time setting, the excess data needs to be manually recovered through a PI backfill task

3. Data Sync Behavior

3.1 Single-column Model

• Subscribes to value changes for each PI Point
• When a PI Point's value changes, the new value is written to the corresponding TDengine subtable
• Each PI Point corresponds to one subtable

3.2 Multi-column Model

• Subscribes to PI Point attribute changes for all elements under an AF template
• When a PI Point attribute value of an element changes, the corresponding column in the corresponding subtable is updated
• Each AF element corresponds to one subtable

4. Multi-column Model Advanced Features

The following advanced options are only available when using multi-column model real-time tasks.

4.1 Sync New Elements

Option	Default	Description
Sync New Elements	Enabled	When enabled, the PI connector monitors newly added elements under templates and automatically syncs their data

Use case: When new devices/assets are continuously being added under AF templates in the PI system, no need to manually restart the task or modify configuration.

4.2 Sync Static Attribute Changes

Option	Default	Description
Sync Static Attribute Changes	Enabled	When enabled, changes to non-PI Point attributes (static attributes) are synced to TDengine TAGs

Use case: When static attributes of AF elements such as description, category, location, etc. may be modified, this keeps TDengine TAGs consistent with PI AF.

4.3 Sync Delete Elements

Option	Default	Description
Sync Delete Elements	Enabled	When enabled, the PI connector monitors element deletion events under templates and deletes the corresponding TDengine subtables

warning

When this option is enabled, deleting an element in PI will cause the corresponding subtable in TDengine to be deleted, and data cannot be recovered. Use with caution.

4.4 Sync Delete Historical Data

Option	Default	Description
Sync Delete Historical Data	Enabled	When enabled, when data at a specific timestamp is deleted in PI, the corresponding column values in TDengine are set to null

4.5 Sync Modify Historical Data

Option	Default	Description
Sync Modify Historical Data	Enabled	When enabled, when historical data is modified in PI, the corresponding data in TDengine is also updated

Use case: PI systems may have data correction operations (e.g., manually modifying anomalous values); enabling this option keeps TDengine data consistent with PI.

5. Best Practices

5.1 High Availability Deployment

• Recommend using Agent proxy mode deployment (see Deployment Architecture) to separate the connector from taosX
• Configure a reasonable restart compensation time to ensure no data loss after task restart
• Monitor task status through Explorer to detect anomalies promptly

5.2 Performance Tuning

Tuning Item	Recommendation
Batch Size	Adjust based on data density; increase appropriately when there are many points with high data frequency
Max Read Delay Per Batch	Adjust based on real-time requirements
Log Level	Use info or warn in production; temporarily switch to debug for troubleshooting

5.3 Task Monitoring

Through the data source list page in Explorer, you can view:

• Task running status
• Data write rate
• Last sync time
• Error logs

We recommend regularly checking task status to ensure real-time sync is running normally.

6. FAQ

How to compensate for real-time task data loss?

If the real-time task interruption duration exceeds the restart compensation time setting, you can compensate through the following steps:

1. Record the time period of the task interruption
2. Create a PI backfill task with a time range covering the interruption period
3. Run the backfill task to recover data
4. After backfill is complete, the real-time task continues normal operation

How to troubleshoot excessive real-time sync latency?

1. Network latency: Check the network latency from taosX/agent to the PI system
2. PI system load: Check the PI Data Archive load
3. TDengine write bottleneck: Check the TDengine cluster write performance
4. Batch size too large: Reduce the batch size appropriately to lower per-batch processing latency
5. Log troubleshooting: Set the log level to debug to view detailed processing times

Do I need to restart the task after adding new points?

• Multi-column model: If the Sync New Elements option is enabled, no restart is needed
• Single-column model: You need to update the model configuration file (add the new point's mapping), then restart the task
• Alternatively, after adding new points in the PI system, re-download the default configuration file and upload it

Multi-column model TAG values not updating?

Confirm whether the Sync Static Attribute Changes option is enabled. If not enabled, TAG values are written only once when the subtable is created and will not be updated afterward.
